When setting up a solar power system, one of the key decisions involves selecting the right cable size. Among the most commonly used options are 4mm² and 6mm² solar cables. While they may look similar at first glance, the choice between them can significantly affect your system’s efficiency, safety, and long-term performance.

Solar cables are responsible for transferring the electricity generated by the solar panels to the inverter and eventually to the power system of your home or facility. The correct cable size ensures minimal power loss and prevents overheating or voltage drops, especially in high-temperature or long-distance setups.

The main factors that influence your choice are current (amperage), voltage, cable length, and installation environment. In general, the thicker the cable, the lower the resistance and the more current it can carry without losing efficiency.

4mm² solar cables are suitable for smaller systems or setups where the cable run is relatively short. For instance, if your panels are installed close to your inverter and the total current doesn’t exceed safe limits, 4mm² is often sufficient. They are also more flexible and easier to handle during installation, especially in tight spaces or balcony systems.

On the other hand, 6mm² cables are more robust and better suited for higher current loads or longer cable runs. If your solar array is installed far from the inverter, using a 6mm² cable helps reduce voltage drop and maintains system performance. This is particularly important for ground-mounted systems or installations with multiple panels wired in parallel.

At the system design stage, it's common for solar professionals to calculate cable size based on voltage drop limits—often keeping it below 3% for optimal performance. As a rule of thumb, if your cable run is longer than 10 meters or you're handling more than 30A of current, moving up to 6mm² is usually advisable.

It’s also essential to consider environmental conditions. Cables running across rooftops or exposed to UV rays and weather need to be durable. Most solar cables today are double-insulated, UV-resistant, and capable of withstanding temperatures up to 90°C. Always ensure your cables meet industry standards like TUV or IEC certifications.

Though SIC Solar is primarily known for manufacturing high-quality solar mounting brackets, their system design approach often includes technical compatibility, such as cable routing and accessory support. For example, when selecting mounting systems, SIC Solar ensures there’s proper spacing for cable management—whether you're using 4mm² or 6mm² wires—so the overall installation remains clean, efficient, and secure.

Whether you’re setting up a residential rooftop system, a balcony unit, or a ground-mounted solar farm, cable selection should never be overlooked. Undersized cables can cause heat build-up and energy losses, while oversized ones may add unnecessary cost and weight. Always base your decision on system specs and installation layout. With quality mounting structures like those from SIC Solar and the correct cabling, your solar project will operate more efficiently from day one.
